Semiconductor company Power Integrations has announced a high-current member of its LinkSwitch-TN2Q automotive switcher IC family which provides up to 850 mA of output current without the need for metal heatsinking. The highly integrated ICs support an input voltage of 30 to 550 VDC, enabling the devices to start up and operate below the required Safety Extra Low Voltage (SELV) threshold in functional safety EV applications.
As electronics in electric vehicles grow more sophisticated, automotive customers need higher supply currents to drive them, highlights Edward Ong, senior product marketing manager at Power Integrations. The 850-mA rating for this new IC represents an increase of 230 % in available output current compared with other members of the LinkSwitch-TN2Q family. LinkSwitch-TN2Q ICs reduce part-count by including control, driver, protection circuitry and a 750 V power MOSFET in an SMD package.
LinkSwitch-TN2Q ICs are AEC-Q100 qualified and support buck, buck-boost and non-isolated flyback converter topologies. Each device incorporates a 750 V power MOSFET, oscillator, on/off control, a high-voltage switched current source for self-biasing, frequency jittering, fast (cycle-by-cycle) current sensing and current limit, hysteretic thermal shutdown, and output over-voltage protection circuitry in a monolithic IC.
LinkSwitch-TN2Q ICs consume very little current in standby, the vendor claims. This results in power supply designs that meet less than 50 mW no-load at 400 VDC input. Comprehensive protection features enable safe and reliable power supplies, including protection against input and output overvoltage, device over-temperature, lost regulation, and power supply output overload or short-circuit faults.
A reference design kit, RDK-707Q, is available for designers wishing to evaluate the LinkSwitch-TN2Q IC family. Devices are priced starting at $1.33 for LNK3209GQ-TL in 10,000-unit quantities. The product is available either directly from Power Integrations or through the company’s authorized worldwide distributors: Digi-Key, Farnell, Mouser and RS Components.
